Autel MaxiSys MS906 PRO-TS OBD2 Scanner User Manual

Table of Contents

  1. Introduction
  2. Features
  3. Package Contents
  4. Getting Started
    • Powering On the Device
    • Connecting to a Vehicle
  5. Using the Scanner
    • Main Menu Overview
    • Diagnostic Functions
    • TPMS Services
    • Additional Features
  6. Software Updates
  7. Troubleshooting
  8. Technical Specifications
  9. Safety Information
  10. Warranty and Support

1. Introduction

Thank you for purchasing the Autel MaxiSys MS906 PRO-TS OBD2 Scanner. This advanced diagnostic tool is designed to offer comprehensive vehicle diagnostics and full TPMS (Tire Pressure Monitoring System) services, making it an essential tool for professional automotive technicians and DIY enthusiasts.

2. Features

  • Full OBD2 Functions: Read and clear diagnostic trouble codes (DTCs), live data, freeze frame data, and more.
  • TPMS Services: Activation, programming, and re-learning of TPMS sensors.
  • Advanced Diagnostics: ECU coding, bi-directional control, and active tests.
  • Extensive Vehicle Coverage: Compatible with a wide range of vehicle makes and models.
  • Wi-Fi and Bluetooth Connectivity: For easy updates and data transfer.
  • User-Friendly Interface: 8-inch touchscreen display with an intuitive interface.

3. Package Contents

  • Autel MaxiSys MS906 PRO-TS OBD2 Scanner
  • Main OBD2 Cable
  • Power Adapter
  • User Manual
  • Quick Reference Guide
  • Carrying Case

4. Getting Started

Powering On the Device

  1. Charging the Device:

    • Connect the power adapter to the scanner and plug it into a power source.
    • Charge the device until the battery is fully charged.

  2. Turning On:

    • Press and hold the power button until the screen lights up.

Connecting to a Vehicle

  1. Locate the OBD2 Port:

    • The OBD2 port is usually located under the dashboard near the driver's seat.

  2. Connect the OBD2 Cable:

    • Plug one end of the OBD2 cable into the vehicle’s OBD2 port.
    • Connect the other end to the scanner.

  3. Establish Connection:

    • Turn on the vehicle’s ignition (engine off).
    • The scanner will automatically detect the vehicle and establish a connection.

5. Using the Scanner

Main Menu Overview

  • Diagnostics: Access vehicle diagnostics functions.
  • Service: Perform maintenance services.
  • TPMS: Access TPMS functions.
  • Data Manager: Manage diagnostic data and reports.
  • Settings: Configure device settings.

Diagnostic Functions

  1. Read Codes:

    • Navigate to Diagnostics > Read Codes.
    • Select the system you want to diagnose (e.g., Engine, ABS).
    • The scanner will display any stored or pending codes.

  2. Clear Codes:

    • Navigate to Diagnostics > Clear Codes.
    • Confirm the action to clear DTCs from the vehicle’s ECU.

  3. Live Data:

    • Navigate to Diagnostics > Live Data.
    • View real-time data from various sensors and systems.

  4. Active Tests:

    • Navigate to Diagnostics > Active Tests.
    • Perform bi-directional control tests on specific components.

TPMS Services

  1. Activation:

    • Navigate to TPMS > Activation.
    • Follow the on-screen instructions to activate TPMS sensors.

  2. Programming:

    • Navigate to TPMS > Programming.
    • Select the appropriate sensor type and follow the instructions to program new sensors.

  3. Relearning:

    • Navigate to TPMS > Relearning.
    • Follow the vehicle-specific procedures to re-learn sensor IDs.

Additional Features

  • Data Manager: Store and manage diagnostic reports.
  • Updates: Check for and install software updates via Wi-Fi.

6. Software Updates

  1. Connect to Wi-Fi:

    • Navigate to Settings > Wi-Fi.
    • Select your network and enter the password.

  2. Check for Updates:

    • Navigate to Updates.
    • The device will automatically check for available updates.

  3. Install Updates:

    • If updates are available, follow the on-screen prompts to download and install.

7. Troubleshooting

  • Connection Issues:

    • Ensure the OBD2 cable is securely connected.
    • Verify the vehicle’s ignition is turned on.

  • Device Not Powering On:

    • Check the battery charge level.
    • Connect to a power source and try again.

  • Error Codes:

    • Refer to the user manual or the manufacturer’s website for a list of common error codes and their solutions.

8. Technical Specifications

  • Display: 8-inch touchscreen
  • Battery: 10000mAh lithium-polymer battery
  • Connectivity: Wi-Fi, Bluetooth
  • Operating Temperature: 0°C to 50°C (32°F to 122°F)
  • Storage Temperature: -20°C to 70°C (-4°F to 158°F)

9. Safety Information

  • Use the device as intended.
  • Avoid exposure to extreme temperatures.
  • Do not disassemble the device.
  • Keep away from water and other liquids.

10. Warranty and Support

  • Warranty: The device comes with a one-year limited warranty.
  • Support: For technical support, visit the Autel website or contact customer service.

Thank you for choosing Autel. We hope this scanner helps you efficiently diagnose and maintain your vehicle. For further assistance, please refer to our online resources or contact our support team.
